How To List Open Files For A Process On Linux

lsof linux

Guide to using the ‘lsof’ command for a process

If you are a frequent user of Linux or Unix systems you must have surely heard the phrase, “In Linux, everything is a file”. This may be categorized as the oversimplification of the concept yet it proves to be very helpful to understand how files in the Linux system works.

Not everything that appears in the Linux environment has to be a file. Sometimes it can be a process, it can be a special file representing the hardware information, directories, and other things.

This tutorial will walk you through in finding all the files which are open for a particular process in Linux.


Introduction To lsof Command

The beauty of the Linux system is that you can control and manage your entire system through the terminal, provided that you know the commands well. Once the commands are known then all the tasks on the terminal become a cakewalk.

lsof stands for ‘List Of Open Files‘. Once you know the long version of the command it becomes very easy for you to understand and use the command in a productive way.

The lsof command displays the lists of open files, sockets, and pipes. You can easily search for the open files using this command. When the lsof command is used without any option it displays all the open files with respect to the active processes which are running.

Note: Make sure you use sudo while executing the commands.


Using The lsof Command

We will study the output of the lsof command in detail. Study the following command.

sudo lsof | less

Note: If we directly run the lsof command, the output is going to be very large and might create confusion to proceed further. Hence, here I’ve used lsof | less command for the convenience of the tutorial.

Output:

gaurav@ubuntu:~$ sudo lsof | less

COMMAND     PID   TID             USER   FD      TYPE             DEVICE  SIZE/OFF       NODE NAME
kdevtmpfs    31                   root  cwd       DIR                0,6      4400          2 /
kdevtmpfs    31                   root  rtd       DIR                0,6      4400          2 /
kdevtmpfs    31                   root  txt   unknown                                         /proc/31/exe
netns        32                   root  cwd       DIR                8,8      4096          2 /
netns        32                   root  rtd       DIR                8,8      4096          2 /
netns        32                   root  txt   unknown                                         /proc/32/exe
rcu_tasks    33                   root  cwd       DIR                8,8      4096          2 /
rcu_tasks    33                   root  rtd       DIR                8,8      4096          2 /
rcu_tasks    33                   root  txt   unknown                                         /proc/33/exe
kauditd      34                   root  cwd       DIR                8,8      4096          2 /
kauditd      34                   root  rtd       DIR                8,8      4096          2 /
kauditd      34                   root  txt   unknown                                         /proc/34/exe

Following are the attributes that are displayed using the lsof command.

ParameterDescription
CommandShows the name of the command that opens the file.
PIDProcess identifier number of the process that opens the file.
TIDThread Identifier number. It can either be a thread or a task number.
UserUser ID or name of the user who is the owner of the process.
FDShows the file descriptor of the file.
TypeType of node associated with the file.
DeviceShows device numbers.
Size/OffShows the size of the file in bytes.
NodeShows the inode number the directory or the parent directory.
NameShows the name of the file system where the process is located.

Listing The Processes

First and foremost it is important for you to obtain the processes that are running and their respective process IDs. Linux provides variety of commands to list the processes along with their attributes like PID, user, directory, etc.

You can use the commands like top, ps, htop, pstree to list the processes on the terminal.

Throughout the tutorial, I’ll be using the top command to do so. The top command provides a dynamic real-time view of a running system. It also displays all the processes and threads currently being managed by the Linux kernel. Study the below-given block to check the output of the top command.

Syntax:

sudo top

Output:

gaurav@ubuntu:~$sudo top

 PID USER      PR  NI    VIRT    RES    SHR S  %CPU %MEM     TIME+ COMMAND
 2703 gaurav   20   0 4286124 1.142g 103584 R  88.2 30.5  87:48.08 Web Content
 1173 mongodb   20   0  288536   6776   3428 S   5.9  0.2   2:34.41 mongod
13765 gaurav   20   0 2931568 131408  47496 S   5.9  3.3   1:42.34 Web Content
    1 root      20   0  225904   6824   4900 S   0.0  0.2   0:27.25 systemd
    2 root      20   0       0      0      0 S   0.0  0.0   0:00.05 kthreadd
    4 root       0 -20       0      0      0 I   0.0  0.0   0:00.00 kworker/0:0H
    6 root       0 -20       0      0      0 I   0.0  0.0   0:00.00 mm_percpu_wq
    7 root      20   0       0      0      0 S   0.0  0.0   0:01.89 ksoftirqd/0
    8 root      20   0       0      0      0 I   0.0  0.0   0:22.32 rcu_sched
    9 root      20   0       0      0      0 I   0.0  0.0   0:00.00 rcu_bh
   10 root      rt   0       0      0      0 S   0.0  0.0   0:03.13 migration/0

In the above block, we can see all the process-related information in one place. From here we can find the PID of the process of which we have to display the open files using the lsof command.

But if you want to find out the process ID of only a particular process and avoid other unwanted processes then use the following command.

Syntax:

sudo top | grep [Process_Name]

Example:

gaurav@ubuntu:~$ top | grep terminal
13819 gaurav   20   0  803336  19728   9160 S   0.3  0.5   0:53.63 gnome-terminal-
13819 gaurav   20   0  803336  19728   9160 S   1.0  0.5   0:53.66 gnome-terminal-
13819 gaurav   20   0  803336  19728   9160 S   0.3  0.5   0:53.67 gnome-terminal-
gaurav@ubuntu:~$

Here we have specifically displayed the process ID of the process which has the string ‘terminal’ in the process name. This method comes handy when you are unaware of the complete process name or the PID.


Displaying The Open Files Related To A Process Using The PID

In the above block, we learned how to obtain the process related information with the help of the top command. Now we will use the PID corresponding to any process on the system and try to display the list of the open files related to that process using the lsof command.

From the above-given output, let us take the process corresponding to the PID 1173 which is highlighted. We will be using the lsof -p [PID] command to do so.

Syntax:

sudo lsof -p [PID]

This command takes the PID of the process as the input and lists all the files corresponding to this PID.

Output:

gaurav@ubuntu:~$ sudo lsof -p 1173
lsof: WARNING: can't stat() fuse.gvfsd-fuse file system /run/user/1000/gvfs
      Output information may be incomplete.
COMMAND  PID    USER   FD   TYPE             DEVICE SIZE/OFF    NODE NAME
mongod  1173 mongodb  cwd    DIR                8,8     4096       2 /
mongod  1173 mongodb  rtd    DIR                8,8     4096       2 /
mongod  1173 mongodb  txt    REG                8,8 38379496 2885608 /usr/bin/mongod
mongod  1173 mongodb  mem    REG                8,8    71776 2624380 /lib/x86_64-linux-gnu/libnss_myhostname.so.2
mongod  1173 mongodb  mem    REG                8,8   101168 2624643 /lib/x86_64-linux-gnu/libresolv-2.27.so
mongod  1173 mongodb  mem    REG                8,8    26936 2624439 /lib/x86_64-linux-gnu/libnss_dns-2.27.so
mongod  1173 mongodb  mem    REG                8,8    10160 2626002 /lib/x86_64-linux-gnu/libnss_mdns4_minimal.so.2
mongod  1173 mongodb  mem    REG                8,8    47568 2624441 /lib/x86_64-linux-gnu/libnss_files-2.27.so
mongod  1173 mongodb  mem    REG                8,8  3004224 2909671 /usr/lib/locale/locale-archive
mongod  1173 mongodb  mem    REG                8,8  2030544 2621501 /lib/x86_64-linux-gnu/libc-2.27.so
mongod  1173 mongodb  mem    REG                8,8   144976 2624627 /lib/x86_64-linux-gnu/libpthread-2.27.so
mongod  1173 mongodb  mem    REG                8,8    96616 2624649 /lib/x86_64-linux-gnu/libgcc_s.so.1
mongod  1173 mongodb  mem    REG                8,8  1700792 2622735 /lib/x86_64-linux-gnu/libm-2.27.so
mongod  1173 mongodb  mem    REG                8,8    14560 2621535 /lib/x86_64-linux-gnu/libdl-2.27.so
mongod  1173 mongodb  mem    REG                8,8    31680 2624646 /lib/x86_64-linux-gnu/librt-2.27.so
mongod  1173 mongodb  mem    REG                8,8  2357760 2890079 /usr/lib/x86_64-linux-gnu/libcrypto.so.1.0.0
gaurav@ubuntu:~$

The files which are open for the process with process ID 1713 are displayed using the lsof command.

Note: GNOME users may encounter the below warning. You can safely ignore it.

lsof: WARNING: can't stat() fuse.gvfsd-fuse file system /run/user/1000/gvfs
      Output information may be incomplete.

Listing Open Files Related To A Process Using The Process Name

The lsof command also provides you with an option to list the open files using the names of the processes. The names should be provided to the command as an input string. See the syntax below to use this option.

Syntax:

sudo lsof -c [Process name]

Example:

sudo lsof -c mysql

Output:

gaurav@ubuntu:~$ sudo lsof -c mysql
lsof: WARNING: can't stat() fuse.gvfsd-fuse file system /run/user/1000/gvfs
      Output information may be incomplete.
COMMAND  PID  USER   FD   TYPE             DEVICE SIZE/OFF    NODE NAME
mysqld  1266 mysql  cwd    DIR                8,8     4096 3154135 /var/lib/mysql
mysqld  1266 mysql  rtd    DIR                8,8     4096       2 /
mysqld  1266 mysql  txt    REG                8,8 24691368 2889411 /usr/sbin/mysqld
mysqld  1266 mysql  mem    REG                8,8     6288 5505444 /usr/lib/mysql/plugin/auth_socket.so
mysqld  1266 mysql  DEL    REG               0,18            28127 /[aio]
mysqld  1266 mysql  DEL    REG               0,18            28126 /[aio]
mysqld  1266 mysql  DEL    REG               0,18            28125 /[aio]
mysqld  1266 mysql  mem    REG                8,8    47568 2624441 /lib/x86_64-linux-gnu/libnss_files-2.27.so
mysqld  1266 mysql  mem    REG                8,8    47576 2624592 /lib/x86_64-linux-gnu/libnss_nis-2.27.so
mysqld  1266 mysql  mem    REG                8,8    39744 2624438 /lib/x86_64-linux-gnu/libnss_compat-2.27.so

The output will be as that of the one in which the Process ID is used instead of the Process name.


Listing files Opened By Network Connections

In Linux, files can also be in the form of information about your network connections, hardware connections etc. We can use lsof command to list the files opened by the network connection. Use the following method.

sudo lsof -i

Output:

gaurav@ubuntu:~$ sudo lsof -i
COMMAND     PID            USER   FD   TYPE  DEVICE SIZE/OFF NODE NAME
systemd-r   969 systemd-resolve   12u  IPv4   17357      0t0  UDP localhost:domain
systemd-r   969 systemd-resolve   13u  IPv4   17358      0t0  TCP localhost:domain (LISTEN)
systemd-r   969 systemd-resolve   15u  IPv4 1685575      0t0  UDP ubuntu:48090->_gateway:domain
avahi-dae  1028           avahi   12u  IPv4   23810      0t0  UDP *:mdns
avahi-dae  1028           avahi   13u  IPv6   23811      0t0  UDP *:mdns
avahi-dae  1028           avahi   14u  IPv4   23812      0t0  UDP *:58999
avahi-dae  1028           avahi   15u  IPv6   23813      0t0  UDP *:37512
mongod     1173         mongodb    6u  IPv4   28149      0t0  TCP localhost:27017 (LISTEN)
mysqld     1266           mysql   19u  IPv4   25992      0t0  TCP localhost:mysql (LISTEN)
apache2    1283            root    4u  IPv6   28140      0t0  TCP *:http (LISTEN)
gaurav@ubuntu:~$

Here we can see the information about the files which are open by the network connection using the lsof -i command.


Conclusion

In this simple tutorial, we have learned how to list open files for a process in Linux using various methods that are easy to use. For more uses of the lsof command, see the lsof man page.
