WireGuard offers a modern approach to VPNs, focusing on simplicity, speed, and strong cryptographic protocols. Running WireGuard on Linux provides a reliable way to secure remote access, route traffic through your server, or connect multiple devices across untrusted networks. The process involves installing the necessary packages, configuring keys, setting up server and client configuration files, and enabling secure communication between peers.
Install WireGuard on Linux
Step 1: Update your package index and install WireGuard. This ensures you have the latest version and dependencies for your distribution. On Ubuntu or Debian-based systems, run:
sudo apt update
sudo apt install wireguard
For other distributions, use the appropriate package manager:
- Fedora:
sudo dnf install wireguard-tools - Arch:
sudo pacman -S wireguard-tools - CentOS/RHEL: See the WireGuard documentation for kernel module and tools installation steps.
After installation, verify with wg --version. If there is no output or an error, check that the kernel module is loaded with sudo modprobe wireguard.
Generate Server and Client Key Pairs
Step 2: WireGuard uses asymmetric cryptography, requiring each device to have its own private and public key. On the server, create a directory for keys and generate them:
sudo mkdir -p /etc/wireguard/keys
cd /etc/wireguard/keys
umask 077
wg genkey | tee privatekey | wg pubkey > publickey
The umask 077 command ensures the keys are only readable by root. Repeat this process on each client device, storing their keys securely. The private key remains on the device, while the public key will be shared with peers as needed.
Configure the WireGuard Server
Step 3: Choose a private IP range for your VPN network, avoiding conflicts with your existing LAN. Common choices include 10.0.0.0/8, 192.168.0.0/16, or 172.16.0.0/12. Assign the server the first address in your chosen subnet, such as 10.8.0.1/24 or 192.168.66.1/24.
Create the main configuration file at /etc/wireguard/wg0.conf:
[Interface]
Address = 10.8.0.1/24
ListenPort = 51820
PrivateKey =
SaveConfig = true
# Enable IP forwarding and NAT for routing client traffic
PostUp = iptables -A FORWARD -i wg0 -j ACCEPT
PostUp = iptables -t nat -A POSTROUTING -o eth0 -j MASQUERADE
PostDown = iptables -D FORWARD -i wg0 -j ACCEPT
PostDown = iptables -t nat -D POSTROUTING -o eth0 -j MASQUERADE
Replace eth0 with your server’s actual network interface name, which you can find using ip route. The PostUp and PostDown directives handle NAT and packet forwarding, allowing clients to access the internet through the VPN.
Set correct permissions on the config file:
sudo chmod 600 /etc/wireguard/wg0.conf
Step 4: Enable IPv4 forwarding in the kernel so your server can route packets between interfaces. Edit /etc/sysctl.conf and ensure the following line is present and uncommented:
net.ipv4.ip_forward=1
Apply the change immediately:
sudo sysctl -p
If you plan to use IPv6, also add net.ipv6.conf.all.forwarding=1.
Step 5: Open the WireGuard UDP port in your firewall. For UFW (Uncomplicated Firewall), run:
sudo ufw allow 51820/udp
Restart UFW to apply the rule:
sudo ufw disable
sudo ufw enable
Add Client Peers to the Server
Step 6: For each client, add a [Peer] section to wg0.conf on the server. Use the client’s public key and assign it a unique IP from your VPN subnet:
[Peer]
PublicKey =
AllowedIPs = 10.8.0.2/32
Repeat for each additional client, incrementing the IP address each time.
Configure the WireGuard Client
Step 7: Install WireGuard on the client device using the same package manager steps as on the server. Generate a key pair for the client as previously described.
Step 8: Create the client configuration file, typically at /etc/wireguard/wg0.conf (Linux), or import into the WireGuard app (Windows, macOS, Android, iOS). Example client config:
[Interface]
PrivateKey =
Address = 10.8.0.2/24
DNS = 8.8.8.8
[Peer]
PublicKey =
Endpoint = :51820
AllowedIPs = 0.0.0.0/0
PersistentKeepalive = 25
Set AllowedIPs = 0.0.0.0/0 to route all traffic through the VPN, or restrict to the VPN subnet for split tunneling. PersistentKeepalive keeps the connection open if the client is behind NAT.
Transfer the server’s public key and endpoint information to the client securely. For mobile devices, you can use qrencode to generate a QR code from the config file and scan it in the WireGuard app:
qrencode -t ansiutf8 -r client.conf
Start and Enable the WireGuard VPN
Step 9: On the server, start the WireGuard interface using systemd and enable it at boot:
sudo systemctl start wg-quick@wg0
sudo systemctl enable wg-quick@wg0
On the client, bring up the interface with:
sudo wg-quick up wg0
To disconnect, use sudo wg-quick down wg0.
Check connection status with:
sudo wg show
The output should display the interface, public keys, allowed IPs, and handshake/traffic statistics. If you see no handshake or traffic, double-check key pairs, firewall rules, and endpoint addresses.
Troubleshooting and Maintenance
WireGuard’s logs and status outputs are helpful for diagnosing problems. Use systemctl status wg-quick@wg0 and journalctl -xe to view service logs. Common issues include:
- Incorrect IP addresses or subnet conflicts between LAN and VPN.
- Firewall rules blocking UDP port 51820 or the chosen port.
- Missing or incorrect
PostUpNAT/forwarding rules on the server. - Key mismatches between client and server.
- Dynamic IP addresses on the server—use dynamic DNS if needed.
When adding new clients, simply generate their keys, add a new [Peer] section to the server config, and reload the configuration with sudo systemctl reload wg-quick@wg0 or by restarting the interface.
For advanced setups, WireGuard supports IPv6, dual-stack configurations, and running multiple tunnels by creating additional configuration files (e.g., wg1.conf).
Setting up WireGuard on Linux streamlines secure networking by reducing configuration complexity and providing robust, fast VPN tunnels. With careful key management and proper routing, you can reliably connect devices and route traffic through your chosen server.
